Product description:
The machine tool is controlled by computer program to processing drilling and tapping at the same time. The rotary table can ensure the processing precision and improve working efficiency. Chinese program operation panel, can set the processing parameters like hole depth and hole distance, which is very easy to operate.
Processing steps:
Manual feeding, automatic drilling, automatic tapping, automatic blanking.
Main accessories and manufacturers:
1. Computer control: Wuxi
2. Pneumatic accessories: Taiwan
3. Ball screw guide: Taiwan
4. Electrical accessories: Germany
5. Bearing: Japan
6. Hybrid servo motor: Shenzhen
7. Hydraulic turntable: Taiwan
Product parameters:
1. Processing material: Cast Iron, Copper, Zinc Alloy
2. Processing range: Round lock head, Triangular lock head
3. Working efficiency: 6000-6500 pcs / 8 hours
4. Size: 1.7m * 1.1m * 1.7m
5. Machine weight: 550kg
6. Machine power: 2.5kw
