Product description:
This equipment is developed for automatic distribution of marbles for computer locks, S-slots, AB beads, padlocks and other lock cores. It has the function of automatically identifying key teeth. It aims to improve the degree of automation and production efficiency in the factory to reduce workers The labor intensity and the increase of production output are designed to focus on the control of the coordinated movement between the servo motor and the pneumatic component, and between the pneumatic component and the pneumatic component. A touch screen display and PLC module control system combined design method is used in the equipment. This equipment is suitable for computer slot, S slot, AB beads, padlocks and other lock cores for automatic distribution of marbles, flat-headed marbles, springs, and door closures.

Processing steps:
Pins distribution station: Insert the key and insert the fixture → identify the tooth flower → servo drive with the pins → the cylinder is pushed to the lower station
Distribution flat spring ball sealing station: induction positioning → servo drive automatically distributes flat spring sealing beads → the cylinder is pushed to the lower station.
Pressing and pressing station: the lock shell is placed in the fixture → induction positioning → marble feeding → flat spring sealing bead feeding → pressurized cylinder pressing.

Main accessories and manufacturers:
1. Ball screw: Taiwan
2. Pneumatic accessories: Taiwan
3. Electrical accessories: Germany
4. Bearing: Japan
5. Hybrid servo motor: Shenzhen

Machine parameters:
1. Processing range: lock case length 60-130mm
2. Working efficiency: 2000-2800 handles / 8 hours (double head)
3. Machine size: 1100m * 850m * 1700m
4. Machine weight: 400 kg
5. Machine power: 1.6kw
